ITEM NUMBER
AL88
Lockplates
d—Bore
D—Outside diameter
B—Width
Verified by Cat Son before quotationPart number · clearance · precision
infos@catson.com.vn
TECHNICAL DATA
Specifications for AL88
Units
Technical Specifications
- Type
- Lockplate
- Material
- Steel
- Locknut Number
- AN88
- Weight
- 0.090 kg 0.198 lb
Dimensional Specifications
- d7
- 18.000 mm 0.7087 in
- L2
- 15.000 mm 0.5906 in
- L3
- 53.000 mm 2.0866 in
- B4
- 36.000 mm 1.4173 in
- L1
- 43.000 mm 1.6929 in
- B3
- 5.000 mm 0.1969 in
